Features
- Volumetric Dispensing with Progressive Cavity Pump: Equipped with a Mohno-style single-rotor screw pump, the system ensures smooth, pulse-free, and continuous output for mid- to high-viscosity materials.
- Supports High Flow Rates & Multiple Container Types: Capable of dispensing up to 1.7 mL/s, compatible with syringes, cartridges, pressure tanks, and central fluid supply systems.
- Synchronized Flow Control: Real-time coordination between dispensing speed and motion path enables precise bead control and uniform pattern consistency.
- Bubble-Free Performance with Suck-Back Control: Built-in degassing and suck-back functions minimize stringing and air entrapment, improving surface finish and coating quality.
- Multiple Smart Operation Modes: Supports TIMED and MANUAL dispensing modes, with additional functions such as suck-back adjustment, specific gravity calibration, and multilingual user interface.
- Modular Mid-Size Head for Easy Integration: Robust and compact dispensing head is designed for flexible installation into desktop automation platforms or inline production systems.
Specification
| Model | MOHNO MASTER V2 | ||
|---|---|---|---|
| Dispensing Range | 0.010 – 1.700 mL/s (depending on pump configuration and settings) | ||
| Dispensing Mechanism | Progressive cavity single-rotor pump (Mohno structure) | ||
| Control Functions | Synchronized flow control, continuous output, motion compensation, suck-back | ||
| Compatible Materials | Sealants, gasket adhesives, CIPG, FIPG compounds, potting materials, RTV silicone, UV adhesives | ||
| Applications | Automotive gasketing, electronics encapsulation, waterproof coating, inline dispensing automation |
※ Dispensing performance may vary depending on fluid viscosity, specific gravity, and particle size. For best results, use with genuine MUSASHI pump heads and control units.
