Features
- PAT Pulse Stabilization: Patented air-pulse circuit ensures consistent pressure and flow for top-tier dispensing stability.
- Model Variants: Four configurations (V5/V2 × N-VHR/GP) to meet high-vacuum or energy-saving needs.
- Industry 4.0 Compatible: Supports remote pressure setting and multiple error signal outputs for seamless smart-factory integration.
- Simple Logs & Low-Level Detection: Built-in dispense logs and near-empty alerts prevent production downtime.
- 100-Channel Memory: Store and recall up to 100 recipes for instant batch changeovers and flexible production.
Specification
| Model | ML-6000XP-CTR-V5-N/P-VHR | ML-6000XP-CTR-V2-N/P-VHR | ML-6000XP-CTR-V5-N/P-GP | ML-6000XP-CTR-V2-N/P-GP | |
|---|---|---|---|---|---|
| Control Method | Digital microcomputer + pneumatic | ||||
| Dispense Modes | Timed / Manual | ||||
| Dispense Pressure | 30 ~ 500 kPa | 5 ~ 200 kPa | 30 ~ 500 kPa | 5 ~ 200 kPa | |
| Dispense Time | 0.001–99.999 s ⇄ 0.01–999.99 s ⇄ 0.1–9,999.9 s (one-touch toggle) | ||||
| Vacuum Pressure | 0 ~ -20.0 kP (600kPa supply) | 0 ~ -10.0 kPa (400kPa supply) | 0 ~ -20.0 kP (600kPa supply) | 0 ~ -10.0 kPa (400kPa supply) | |
| Main Functions | Operation log, dispense counter, alert outputs, low-level warning, channel register/switch/copy, key lock, interval dispense, language switch, mode switch, stopwatch, auto-increment, auto-slope, express shot | ||||
| Channels | 100 CH | ||||
| Power Supply | DC24V ± 10% | ||||
| Power Consumption | 12W | ||||
| Dimensions (WxDxH) | W180 x D185 x H83 mm | ||||
| Weight | 2.2 kg | 2.0 kg | |||
※ Dispense performance depends on material viscosity and particle size.
