Features
- Cost Reduction: Streamlines handling processes to lower operational costs.
- Lightweight Design: Achieves an 80% reduction in net weight compared to the original model (LTU-025B-R).
Specification
| Model | Unit | LTU-025P☐ |
|---|---|---|
| Dimensions (W x L x H) | mm | 100 x 250 x 29.7 |
| Working Fluid | Air (non-corrosive, non-flammable gases) | |
| Ambient Temperature | ºC | 0 ~ +50 (Do not allow freezing) |
| Lubrication | Not required | |
| Operating Pressure Range | kPa | 0 ~ 200 |
| Flatness | µm | 100 |
Notes：
1. ☐：A：Non-connector type B：Single-side connector type C：Double-side connector type
2. Supply air must be filtered through a 5µm or finer air filter, and an oil mist separator with a filtration level of 0.01µm.
