Features
- Ultra-Micro Dispensing: Delivers as low as 0.00001mL, stable across various viscosities.
- Smart Channel Memory: Stores up to 400 settings with auto dispensing setup and error logs.
- Durable Plunger Pump: Consistent output with long service life and reduced maintenance.
- Real-Time Error Alerts: Built-in overpressure and abnormal discharge detection.
- Wide Container Compatibility: Supports MUSASHI syringes, cartridges, and tanks (10–340mL).
- Multilingual System Interface: English, Japanese, and Chinese UI with D-sub I/O for seamless automation integration.
Specification
| Model | MPP-5-H-S | ||
|---|---|---|---|
| Control Method | Digital microcomputer / Volumetric with plunger | ||
| Dispense Volume | 0.00001mL – 0.50800mL (based on pump head) | ||
| Pressure Range | 0.001 to 0.500 MPa | ||
| Dispensing Time | 0.01 to 99.99 seconds | ||
| Dispensing Speed | 1 – 24 mm/s (based on pump head type) | ||
| Communication | D-sub 25-pin I/O control | ||
| Compatible Containers | 10–70mL syringes/cartridges, 170–340mL pressure tanks | ||
| Power Supply | AC100–240V, 50/60Hz, 75W |
※ Performance may vary with viscosity, gravity, and particle size. Use genuine MUSASHI parts for optimal results.
